Specification
Model | LTR50 | |
Rated Capacity | kg | 5000 |
Mast width | mm | 180 |
Max.Gradeability (No load/Full load) | % | <35° |
Frame articulation | mm | Front500 Rear300 |
Weight | kg | 5720 |
Mast Tilt Angle(F/R) | Deg | 12° |
Dimension | mm | 4400*2085*2650 |
Tires | mm | 16/70-24 |
Turning radius (outside tires) | mm | 4800 |
Lift Height | mm | 3000 |
Fork length (standard) | mm | 1220 |
Ground Clearance(Bottom of mast) | mm | 320 |
Mast Lowered Height | mm | 2400 |
Engine | Yunnei4102 | |
Rated output/r.p.m. | kw | 78/3200 |
Rated torque/r.p.m. | N·m | 285/1200-2800 |
No.of Cylinder | 4 | |
No.of Cylinder | mm | 81x97 |
Displacement | L | 1.99 |
Drive Model | 4WD | |
Gearbox | 280 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
