Specification
Model |
| LTQE1214 |
Measure |
|
|
Max. Working height | m | 14 |
Max. Platform height | m | 12 |
Max. Horizontal reach | m | 8 |
Max. Up Stover clearance | m | 5 |
Platform dimensions(LxW) | m | 1.1x0.65 |
Length(stowed) | m | 5.3 |
Width(stowed) | m | 2 |
Height(stowed) | m | 2.05 |
Wheelbase | m | 2 |
Ground clearance(center) | m | 0.2 |
Productivity |
|
|
Max.Lift capacity | kg | 230 |
Max.Platform occupancy |
| 2 |
Platform rotation |
| ±80° |
Vertical jib rotation |
| 140° |
Turntable rotation |
| 355° |
Turntable tail swing | m | 0.13 |
Drive speed (stowed) | km/h | 3 |
Drive speed (raised) | km/h | 0.8 |
Gradeability |
| 25% |
Max. Working slope |
| 3°/3° |
Turning radius(inside) | m | 2.2 |
Turning radius(outside) | m | 4.73 |
Drive & steer mode |
| 4x2x2 |
Tire type |
| 0.59x0.19 |
Power |
|
|
Battery |
| 48V/320Ah |
Pump electric motor power |
| 7.5 |
Drive electric motor power | kw | / |
Control voltage |
| 24V DC |
Charger |
| 48V/50A |
Weight | kg | 5500 |
Standards Compliance |
| EN280：2013+Al：2015 GB25849-2010 |
Adresse: No. 506, Xinglinwan Road, Jimei District, Xiamen City, Fujian Province, Xiamen, Fujian, CN
With the mission of making the world greener, LTMG has focused on the construction machinery industry for more than 20 years. From R&D and production to reaching global customers, LTMG has always been quality-oriented and excellent service, conveying the power of China's machinery manufacturing to the world
